Vertical Multi-Stage Pumps

black and gold vertical water pump

Vertical Multi-Stage Pumps are available from 5 to 500 GPM, with all 316 stainless steel hydraulics for superior durability, efficiency, and performance. A small footprint, premium motor, and rugged components ensure long operating life, providing a water-pumping solution in nearly any demanding application.

Find your Taco Sales Representative
Click below to get in touch with your local Taco supplier:
Find a Rep
We’re Here to Help
Support is only a click away! Our dedicated customer service and tech support teams are waiting to hear from you.
Support
Performance Data
  • Flow Range: 5 to 500 GPM (20 to 2,000 L/Min)
  • Head Range: Up to 750 feet (230 M)
  • Maximum Working Pressure: Up to 460PSI
  • Liquid Temp: +14˚F (-10˚C) to +248˚F (120˚C)
  • Clockwise rotation (looking at the pump from the top down)
  • Round ANSI flange standard
  • 3600 RPM Performance Curve Available
Features
  • All 316 SS wetted components for superior durability, efficiency, and Performance Curve over a wide variety of applications (except G version of 30-45-65-95VR with CI casing and upper flange standard)
  • Rugged NEMA motor mounting with oversized thrust bearing ensures long operating life in the toughest jobs (special, heavy-duty motor bearing not required)
  • Removable stainless steel seal plate with jack screw taps provided for ease of service
  • In-line suction and discharge connections with round ANSI flanges fit widest range of applications and provide for convenient, compact installation with a small footprint
  • NEMA standard motors; TEFC enclosures, 1 & 3 phase voltages available with all 3-phase motors of premium efficiency design and inverter duty rated
Applications
  • Heating, Ventilation, and Air Conditioning (HVAC)
  • Water Supply and Pressure Boosting
  • Light Industry
  • Irrigation and Agriculture
